1-3/8 Inch Diamond Hole Saws

Wet cutting is generally recommended for diamond hole saws working on tile, porcelain, and stone, as water cools the bit and extends its lifespan. Dry cutting can be performed for short durations, but continuous dry use generates excess heat that can degrade the diamond segments and reduce cutting performance significantly.

The pilot bit centers the hole saw precisely on the tile surface before cutting begins, preventing the bit from skating or shifting on smooth, hard surfaces like porcelain or glazed ceramic. Using a pilot bit improves hole accuracy, reduces breakage risk, and helps maintain a cleaner, more professional finish on finished tile work.

To prevent cracking, apply steady, consistent pressure without forcing the bit, use water for cooling and lubrication, and start at a low RPM. Mark the hole position accurately and consider using masking tape over the drilling area to reduce surface vibration and chipping on glazed or polished tile surfaces.

For a 1-3/8 inch diamond hole saw, a speed of approximately 500–1,200 RPM is typically recommended depending on the tile material. Harder materials like porcelain and granite require slower speeds with more water cooling. Always consult the manufacturer's specifications and avoid high RPM settings that can overheat and prematurely wear the diamond segments.

Yes, diamond hole saws are suitable for cutting glass tile when used with water cooling and at an appropriate low RPM. Glass tile is especially prone to cracking under pressure, so a light, steady feed rate is essential. DI Tool offers specialized diamond cutting solutions designed to handle glass tile for backsplash and decorative installation projects.

The lifespan of a diamond hole saw depends on the material being cut, cutting technique, and whether water cooling is used. On average, a quality diamond hole saw can complete dozens to hundreds of holes in ceramic or porcelain tile before the segments wear down. Consistent wet cutting and avoiding excessive pressure will significantly extend service life.
